Description
| Specifications |
VG-640 |
VG-540 |
| Printing technology |
Piezoelectric inkjet |
| Media |
Width |
8.3in – 64in (210mm – 1,625 mm) |
8.3in – 54in (210mm – 1,371mm) |
| Thickness |
Maximum 39 mil (1.0 mm) with liner for printing |
|
Maximum 16 mil (0.4 mm) with liner and 9 mil (0.22mm) without liner for cutting |
| Roll outer diameter |
Maximum 8.3 in. (210 mm) |
| Roll weight |
Maximum 88 lbs. (40 kg) |
Maximum 66 lbs (30 kg) |
| Core diameter *1 |
3 in. (76.2 mm) or 2 in. (50.8 mm) |
| Printing/cutting width *2 |
Maximum 63 in (1,600 mm) |
Maximum 53 in (1,346 mm) |
| Maximum speed (dual CMYK, 2-pass) |
375 sqft/hr. |
345 sqft/hr. |
| Standard speed (dual CMYK, 6-pass) |
153 sqft/hr. |
144 sqft/hr. |
| Replacable Ink Pouch |
Type |
Roland TrueVIS INK |
|
Capacity |
500 cc CMYK Lc Lm Lk +WH |
|
Colors |
CMYKCMYK, CMYKLcLmLk, CMYKLcLmLk+WH |
| Printing resolution (dots per inch) |
Maximum 900 x 900 dpi |
| Cutting speed |
10 to 300 mm/s |
| Blade force |
30 to 500 gf |
| Blade offset |
0 to 0.059 in (0 to 1.5 mm) |
| Software resolution (when cutting) |
0.000984 in/step (0.025 mm/step) |
| Distance accuracy (when printing) *3 *4 |
Error of less than ±0.3 % of distance traveled, or ±0.3 mm, whichever is greater |
| Distance accuracy (when cutting) *3 |
Error of less than ±0.4% of distance traveled, or ±0.3 mm, whichever is greater |
| When distance correction has been performed (when the setting for [CUTTING MENU] – [CALIBRATION] has been made): Error of less than ±0.2% of distance traveled, or ±0.1 mm, whichever is greater |
| Repeatability (when cutting) *3 *5 |
±0.1 mm or less |
| Alignment accuracy for printing and cutting *3 *6 |
±0.5 mm or less |
| Alignment accuracy for printing and cutting when reloading media *3 *7 |
Error of less than ±0.5% of distance traveled, or ±3 mm, whichever is greater |
| Media heating system *8 |
Print heater |
Setting range for the preset temperature: 86 to 112ºF (30 to 45ºC) |
| Dryer |
Setting range for the preset temperature: 86 to 122ºF (30 to 50ºC) |
| Connectivity |
Ethernet (10BASE-T/100BASE-TX, automatic switching) |
| Power-saving function |
Automatic sleep feature |
| Power requirements |
AC 100 V to 120V ±10%, 9.8A, 50/60Hz |
AC 100 to 120 V ±10%, 7.5A, 50/60 Hz or |
| Power consumption |
During operation |
1,270 W |
Approx. 955 W |
| Sleep mode |
40 W |
Approx. 15.1 W |
| Acoustic noise level |
During operation |
64 dB (A) or less |
| During standby |
41 dB (A) or less |
| Environmental |
Power on |
Temperature: 15 to 32ºC (59 to 90ºF) [20ºC (68ºF) or more recommended], Humidity: 35 to 80%RH (no condensing) |
| Power off |
Temperature: 5 to 40ºC (41 to 104ºF), humidity: 20 to 80%RH (no condensing) |
| Dimensions (with stand) |
116(W) x 29.4(D) x 51.6(H) in
2,945(W) x 745(D) x 1,310 (H) mm |
105.8(W) x 29.4(D) x 51.6(H) in
2,685(W) x 745(D) x 1,310(H) mm |
| Weight (with stand) |
451.9 lbs (205 kg) |
421 lbs (191 kg) |
| Included items |
Stand, power cord, blade, blade holder, media clamps, media holder, replacement blade for separating knife, software RIP, user’s manual, etc. |
|
|
 |
|
|
|
