Description
Specifications
| DA-640 | ||
|---|---|---|
| Printing Method | Piezo ink-jet method | |
| Media | Width | 10.2 – 64 in (259 – 1,625 mm) |
| Thickness | Max. 0.04 in (1.0 mm) with liner | |
| Roll outer diameter | Max. 7.1 in (180 mm) | |
| Roll weight | Max. 66 lb. (30 kg) | |
| Core diameter | 3.0 in or 2.0 in (76.2 mm or 50.8 mm) | |
| Printing Width (*1) | Max. 63.6 in (1,615 mm) | |
| Ink | Type | DIMENSE Ink 500 ml Cartridge |
| Colors | Four colors (cyan, magenta, yellow, black); Structural Ink | |
| Printing Resolution (dots per inch) | Max. 1,200 dpi | |
| Media Heating System (*2) | Print heater set temperature: 86 – 104°F (30 – 40°C) Oven set temperature: 302 – 716°F (150 – 380°C) |
|
| Connectivity | Ethernet (100BASE-TX/1000BASE-T, automatic switching) | |
| Power-saving Function | Automatic sleep feature | |
| Rated Input | Printer: 200-240 Va.c. 50/60 Hz 3.5 A Oven 1: 200-240 Va.c. 50/60 Hz 16 A Oven 2: 200-240 Va.c. 50/60 Hz 16 A |
|
| Power Consumption | During Operation | Approx. 4,860 W |
| Sleep Mode | Approx. 50 W | |
| Acoustic Noise Level | During Operation | 69 dB (A) or less |
| During Standby | 53 dB (A) or less | |
| Dimensions (Width × Depth × Height) | 114.3 × 37.1 × 60.9 in (2,902 × 942 × 1,548 mm) | |
| Weight | 668 lb. (303 kg) | |
| Environment | During Operation (*3) | Temperature: 68 – 86°F (20 – 30°C), Humidity: 40 – 65 %RH (no condensation) |
| Not Operating | Temperature: 41 – 104°F (5 – 40°C), Humidity: 20 – 80 %RH (no condensation) | |
| Included Items | Dedicated stand, power cords, oven, media take-up unit, media holders, separating knife, replacement blade, cleaning liquid bottle for maintenance, drain bottle, User’s Manual, software (VersaWorks, Roland DG Connect), etc. | |
