Description
Specifications
| JV330-130 | JV330-160 | ||
|---|---|---|---|
| Print head | On-demand piezo head (2 staggered layout) | ||
| Print resolution | 600dpi, 800dpi, 900dpi, 1200dpi | ||
| Print gap | By manual 3 levels (2.0/2.5/3.0 mm) | ||
| Ink | Type/Color | Eco-solvent ink SS21 (C, M, Y, K, Lc, Lm, Lk, Or, W) SS22 (C, M, Y, K, Lc, Lm, Lk, Or, W) BS4 (C, M, Y, K) |
|
| Capacity | SS21: 2L ink pack (500ml ink pack only for White ink) SS22: 1L ink pack (500ml ink pack only for White ink) BS4: 2L ink pack |
||
| Ink circulation | Circulation in damper MCTv2 | ||
| Maximum print width | 1,360mm (53.5″) | 1,610mm (63.4″) | |
| Media | Maximum width | 1,370mm (53.9″) | 1,620mm (63.8″) |
| Thickness | 1 mm or lower | ||
| Roll diameter | φ250 mm or less | ||
| Mountable no. | Max. Three rolls | ||
| Roll weight | One roll：Max. 45 kg (99.2 lb) or less Three rolls：Total 90 kg (198.4 lb) or less |
||
| Roll inside diameter | 2 inch / 3 inch | ||
| Media cutting | Auto cutting by cutter of head unit *1 | ||
| Interface | Ethernet 1000 BASE-T (Recommended) / USB2.0 Hi-speed | ||
| Certifications | VCCI class A, FCC class A, ETL IEC 62368-1, CE Marking (EMC, Low voltage, Machinery directive, and RoHS), CB, REACH, Energy Star, RCM, KC, UKCA |
||
| Power supply | Main unit：(Single phase AC100-120/200-240V±10％, 50/60Hz±1Hz) ×2 | ||
| Power consumption | Max. 1,440 W or less x 2 / Min. 4.5 W or less (Sleep mode) | ||
| Operational environment | Temperature: 20–30 °C (68–86 °F) Humidity: 35–65% Rh (Non condensing) Recommended temperature: 20–25 °C (68–77 °F) Dust level: General office level |
||
| Dimensions (W×D×H) | 2,920 × 1,215 × 1,305 mm (115.0 x 47.8 x 51.4″) |
3,170 × 1,215 × 1,305 mm (124.8 x 47.8 x 51.4″) |
|
| Weight | 358 kg (789.2 lb) | 368 kg (811.3 lb) | |
*1 Cut shape can be V-shaped cut or straight cut.
Ink set
| SS21 ［C,M,Y,K,Lc,Lm,Lk,Or,W］ |
C M Y K |
|---|---|
| C M Y K Lc Lm Lk Or | |
| C M Y K Lc Lm W | |
| SS22 ［C,M,Y,K,Lc,Lm,Lk,Or,W］ |
C M Y K |
| C M Y K Lc Lm Lk Or | |
| C M Y K Lc Lm W | |
| BS4 ［C,M,Y,K］ |
C M Y K |
