Description
Specifications
| UCJV330-130 | UCJV330-160 | ||
|---|---|---|---|
| Print head | On-demand piezo head (2 staggered layout) | ||
| Print resolution | Y: 600, 1200 dpi X: 600, 1200, 1800 dpi | ||
| Print gap | By manual 3 levels (2.0/2.5/3.0 mm) | ||
| Ink | Type/Color | LUS-170：C,M,Y,K,Lc,Lm,W,Cl LUS-175：C,M,Y,K,Lc,Lm,W,Cl *1 LUS-200：C,M,Y,K,W LUS-190：C,M,Y,K,W *1 LUS-210：C,M,Y,K,W *1 |
|
| Capacity | 1L bottle | ||
| Ink circulation | Circulation in damper MCTv2 | ||
| Maximum print width | 1,360mm (53.5″) | 1,610mm (63.4″) | |
| Media | Maximum width | 1,370mm (53.9″) | 1,620mm (63.8″) |
| Thickness | 1 mm or lower | ||
| Roll diameter | φ250 mm or less | ||
| Mountable no. | Standard : 1 roll / Option : 3 rolls (with the Media changer) | ||
| Roll weight | One roll：Max. 45 kg (99.2 lb) or less Three rolls：Total 90 kg (198.4 lb) or less |
||
| Roll inside diameter | 2 inch / 3 inch | ||
| Media cutting | Auto cutting by cutter of head unit *2 | ||
| Cutting function | Cutting speed | Max. 300 mm/s | |
| Acceleration | Max. 0.5G | ||
| Cutting pressure | 10 – 450 gf | ||
| Cutter response times | 10 times/sec | ||
| Repeatability | ±0.2 mm (Excluding shrinkage / expansion caused by the film temperature) | ||
| Interface | Ethernet 1000 BASE-T (Recommended) / USB2.0 Hi-speed | ||
| Certifications | VCCI class A, FCC class A, ETL IEC 62368-1, CE Marking (EMC, Low voltage, Machinery directive, and RoHS), CB, REACH, Energy Star, RCM, KC, UKCA |
||
| Power supply | Single phase AC100-120V±10% /12A or Single phase AC200-240V±10% /6A 50/60Hz±1Hz |
||
| Power consumption | Max.1,440W or less ×1 / 800W (Continuous operation) / 4.5W or less (Sleep mode) | ||
| Operational environment | Temperature: 20–30 °C (68–86 °F) Humidity: 35–65% Rh (Non condensing) Recommended temperature: 20–25 °C (68–77 °F) Dust level: General office level |
||
| Dimensions (W x D x H) | 2,640 x 800 x 1,480mm (103.9 x 31.5 x 58.3″) |
2,890 x 800 x 1,480mm (113.8 x 31.5 x 58.3″) |
|
| Machine weight | 217kg (478.4 lb) | 227kg (500.4 lb) | |
