Description
Specifications
| JFX600-2513 | ||
|---|---|---|
| Head | On-demand Piezo head 16 printheads (4×4 lines in a staggered layout) |
|
| Print resolution | 600, 1,200dpi | |
| Ink | Type | Flexible UV curable ink : LUS-120 (C, M, Y, K, Lc, Lm, W, Cl) *1 |
| Flexible UV curable ink : LUS-150 (C, M, Y, K, Lc, Lm, W) *1 | ||
| Flexible UV curable ink : LUS-211 (C, M, Y, K, W, Cl) *1 *2 | ||
| Hard UV curable ink : LH-100 (C, M, Y, K, Lc, Lm, W, Cl) | ||
| Primer: PR-200 *3 | ||
| Ink Supply system | Supplied from 1-liter bottles for each color | |
| Ink circulation system *4 | White ink circulation using Mimaki Circulation Technology (MCT) | |
| Maximum diagram dimensions (W×D) | 2,500×1,300 mm (98.4×51.2″) | |
| Media | Dimensions (W×D) | Up to 2,500×1,300 mm (98.4×51.2″) |
| Height | Max. 60 mm | |
| Weight | Less than 50 kg/m2 (10.2 lb./ft2), non concentrated load | |
| Media absorption | Blower adsorption type + foot switch | |
| Number of absorption area partitions | 2 partitions (X-axis direction) | |
| Curing device | LED-UV system | |
| Interface | Ethernet 10GBASE-T | |
| Safety standard | UL 775 ETL / CE Marking (EMC, Machinery directive, and RoHS) / REACH / EAC | |
| Power supply | (Single phase, AC200-240V±10%, 50/60Hz±1Hz, 24 A) ×3 | |
| Power consumption | INLET1 to 3 | Each INLET: Less than 4.8 kVA | |
| Installation environment | Temperature | 20 – 30 °C (68 – 86 °F) |
| Relative humidity | 35 – 65％Rh (Non condensing) | |
| Accuracy maintained temperature | 20 – 25 °C (68 – 77 °F) | |
| Temperature gradient | Less than ± 10 °C/h (± 18 °F/h) | |
| Dust | Similar to standard office environments | |
| Assembled Dimensions (W×D×H) | Approx. 5,300×2,850×1,700 mm (208.7×112.2×66.9″) or less | |
| Weight | Approx. 1,200 kg (2,645.5 lbs.) or less | |
