Description
Product Overview
The Han-Bond SDigit-2412 One-Click Pattern Digitizer is a professional large-format digitizing solution developed for garment manufacturers, fashion designers, textile factories, footwear companies, furniture manufacturers and other industries requiring accurate pattern digitization.
Equipped with Han-Bond’s One-Click Digitizing technology, the SDigit-2412 automatically captures paper patterns and converts them into editable CAD files with high precision and excellent efficiency. Supporting DXF, PLT and PDF file formats, it is compatible with most mainstream CAD software.
With a 2400 × 1200 mm scanning area, 3300 mm/min scanning speed and 0.15 mm scanning accuracy, the SDigit-2412 is ideal for oversized garment patterns and industrial production requiring fast, reliable and accurate digitizing.
Technical Specifications
| Item | Specification |
|---|---|
| Model | SDigit-2412 |
| Brand | Han-Bond |
| Condition | Brand New |
| Machine Type | One-Click Pattern Digitizer |
| Scan Area | 2400 × 1200 mm |
| Scan Speed | 3300 mm/min |
| Scan Time | 57 Seconds |
| Scan Accuracy | 0.15 mm |
| Output Formats | DXF, PLT, PDF |
| Compatible CAD Software | Most Mainstream CAD Systems |
| Power Supply | AC110V / 220V ±20%, 50–60Hz |
| Power Consumption | 180W |
| Machine Dimensions | 2900 × 1368 × 970 mm |
| Package Dimensions | 3000 × 1420 × 510 mm |
| Net Weight | 218 kg |
| Gross Weight | 330 kg |
Key Features
✔ Han-Bond One-Click Digitizing Technology
✔ Large 2400 × 1200 mm Scanning Area
✔ High-Speed Scanning up to 3300 mm/min
✔ High Precision 0.15 mm Accuracy
✔ Supports DXF, PLT and PDF Output
✔ Compatible with Major Garment CAD Software
✔ Automatic Pattern Recognition
✔ Industrial-Grade Stable Performance
✔ Easy One-Click Operation
✔ Suitable for Large Pattern Digitizing
Applications
• Garment Pattern Digitizing
• Fashion Pattern Development
• Apparel Manufacturing
• Textile Production
• Footwear Pattern Making
• Leather Goods Design
• Bag Pattern Development
• Upholstery Manufacturing
• Furniture Industry
• Automotive Interior Pattern Design
Compatible Materials
• PVC Vinyl
• Self-Adhesive Vinyl
• PET Film
• Transparent Film
• Backlit Film
• Window Film
• Banner Material
• Wallpaper
• Canvas
• Synthetic Paper
Why Choose Han-Bond SDigit-2412
The Han-Bond SDigit-2412 One-Click Pattern Digitizer is designed for manufacturers that require a larger working area and higher production efficiency.
Compared with traditional manual digitizing methods, the SDigit-2412 dramatically reduces digitizing time while maintaining high scanning accuracy. Its extra-large scanning area makes it suitable for oversized garment patterns, furniture templates, automotive interiors and other industrial applications.
Supporting industry-standard DXF, PLT and PDF formats, the SDigit-2412 integrates easily into existing CAD workflows and helps improve production efficiency while reducing labor costs.
FAQ
Is the Han-Bond SDigit-2412 a brand new machine?
Yes. We supply brand new Han-Bond SDigit-2412 One-Click Pattern Digitizers.
What is the scanning area?
The maximum scanning area is 2400 × 1200 mm.
What is the scanning speed?
The maximum scanning speed is 3300 mm/min.
What is the scanning accuracy?
The scanning accuracy is 0.15 mm.
Which file formats are supported?
The machine supports DXF, PLT and PDF output formats.
Is it compatible with garment CAD software?
Yes. The SDigit-2412 is compatible with most mainstream garment CAD systems.
Can you provide international shipping?
Yes. Worldwide shipping is available.
