Xaar Irix Core 80W Printhead System – XP12800073

The Xaar Irix Core 80W printhead with purple insulator is suitable for a wide range of oil, solvent and water based ink systems. This printhead serves as a direct replacement for the discontinued Xaar XP12800005 and XP12800006 heads, and can be used instead of XP12800071, offering identical performance, quality and printer compatibility. No firmware changes are required in the printer software either. The ink connections on the Xaar 128 and Xaar Irix are 3.1 mm in diameter, therefore the recommendation for the tubing is for 3mm ID tubing. The exact choice of tubing would depend upon the inks you are using.

Product specification:

Active nozzles: 128
Nozzle density (NPI): 185
Print swathe (mm): 17
Dimensions (mm): 37.2 x 11.3 x 40.8
Mass (g): 15.5
Colour of insulator: Purple
Drop size (pL): 80
Drop velocity (m/s): 5
Max frequency (kHz): 5.5
Linear speed (m/s @ 180 DPI): 0.78
Print distance (mm): <5
Max angular deviation (degrees): 1.8
Drop velocity variation 3σ (m/s): +/- 0.50
Country of origin : United Kingdom

Printer Compatibility

Algotex Streamjet 180

Allsign E-Type

Ampla Digital Targa Plus 1808/1812/1816/2508/2512/2516/3208/3216
Ampla Digital targa-plus-3212

Atexco Aprint-3308B

DGI REX-62/VT-100D/VT-130D/VT-62/VT-92/VTII-62/VTII-62P/VTII-92/VTII-92P/VTIII-98D/VTIII-98DP/VTIII-98DS/VTIV-62/VTIV-92/VTIV-98/VTV-1604/VTV-1606/VTV-2504/VTV-2506

HP Fresco 1800/3200
HP Fresco HiQ 4C 1800
HP Fresco HiQ 4C 3200
HP Fresco HiQ 8C 1800
HP Fresco HiQ 8C 3200
HP Salsa 1500/2400/3200
HP Scitex Grandjet 2.2M/3.5M/5M
HP Scitex XL1200 2.2M (XLJet 2)
HP Scitex XL1200 3.2M (XLJet 3)
HP Scitex XL1200 5M (XLJet 5)
HP Scitex XL1500 2.2M (XLJet +2)
HP Scitex XL1500 3.2M (XLJet +3)
HP Scitex XL1500 5M (XLJet +5)
HP Scitex XLJet 2 Premium
HP Scitex XLJet 3 Premium
HP Scitex XLJet 5 Premium

JHF Vista 1808/2508/3312

SPRIN USA SPK-260/SPK-320/SPR-185/SPR-260/SPR-320
SPRIN USA XL-185

Squid Ink CoPilot 128
